Ballista Framesets Available Now

fbm ballista frameset trans red front angle

The FBM Ballista Frameset

designed for hardcourt bike polo

Handcrafted in New York by FBM Bike Co. the Ballista is a tig welded, 4130 chromoly frameset designed for the specific needs of hardcourt bike polo players.

We started with the original FBM Sword frame geometry and tube set, and, with input from Evan George and Koyo Maeda of Seattle’s The Assassins, designed the Ballista. We increased the height of the headtube for a more upright riding position, decreased the height of the seat tube for more standover clearance above the top tube, used a bulge butted seat tube for more strength in the top tube / seat stay junction, and added optional front and rear canti mount brakes and optional front disc brakes. Check out the complete specs and more photos here.

Evan and Koyo, who rode prototype Ballistas in the 2013 Worlds, where The Assassins took 3rd place and Koyo was named MVP, have this to say about the frameset: “It’s the jam saucy, real buttery” – Koyo, “This is the dopest bike, it’s super fun to ride, I love it” – Evan.

The FBM Ballista framesets are available from your local bike shop, online direct from Last Call Distro, or you can give us a call at 607-729-2803.

Read The Rest

The FBM Ballista Frameset

Koyo and Evan at the 2013 Worlds

Introducing the FBM Ballista Frameset

designed for hardcourt bike polo

Handcrafted in New York by FBM Bike Co. the Ballista is a tig welded, 4130 chromoly frameset designed for the specific needs of hardcourt bike polo players.

We started with the original FBM Sword frame geometry and tube set, and, with input from Evan George and Koyo Maeda of Seattle’s The Assassins, designed the Ballista. We increased the height of the headtube for a more upright riding position, decreased the height of the seat tube for more standover clearance above the top tube, used a bulge butted seat tube for more strength in the top tube / seat stay junction, and added optional front and rear canti mount brakes and optional front disc brakes. Check out the complete specs below.

Evan and Koyo, who rode prototype Ballistas in the 2013 Worlds, where The Assassins took 3rd place and Koyo was named MVP, have this to say about the frameset: “It’s the jam saucy, real buttery” – Koyo, “This is the dopest bike, it’s super fun to ride, I love it” – Evan.

We’re taking pre-orders from now until the end of the year for a batch of framesets that will be available to ship in February 2014. The retail price is $750; we require a 50% deposit to place a pre-order; the other 50% plus freight will be due prior to shipping. Orders can be placed online at Last Call, through your local FBM dealer, or you can give us a call at 607-729-2803.

fbm ballista profile

Frame Specs
Size Top Tube Length Seat Tube Length Head Tube Angle Seat Tube Angle Chain Stay Length Bottom Bracket Drop Stand Over Height
(approx)
Small 523mm 460mm 73.5 74.5 395mm 55mm 755mm (29.7″)
Medium 544mm 500mm 74 74 395mm 55mm 795mm (31.3″)
Large 569mm 540mm 74.5 73.5 395mm 55mm 832mm (32.8″)
Head Tube 1-1/8″
Bottom Bracket Width 68mm
Seat Post Diameter 27.2mm
Rear Dropout Spacing 120mm
Brake Options Removable Canti or None
Material 4130 Chromoly
COLORS Black, Clear, Trans Blue, Trans Red
Fork Specs
Steerer Tube 1 piece CNC machined
300mm long
1-1/8″ threadless
Blades 1″ tapered to 1/2″
Dropouts 3/16″ thick laser cut
Axle Spacing 100mm
Fork Length
(crown to center of axle)
375mm
Rake 35mm
Brake Options Removable Canti, 51mm I.S. Disc, Both or None
Material 4130 Chromoly
COLORS Black, Clear, Trans Blue, Trans Red

Flat BlackClearTrans Bluetrans-red-color-sample

Sword Framesets In Stock Now

fbm sword headbadge closeup

The FBM Sword SQ framesets in new colorways are available now.

The latest colorways are flat black, clear and trans gold and it’s available in three sizes 48cm, 52cm and 56cm.

The Sword SQ frameset has traditional track geometry, is tig welded 4130 chromoly, and is handcrafted in the FBM machine shop in Johnson City, NY. Check the Sword page for complete specs and help selecting your size.

Thanks to everyone that pre-booked their frames.  The Sword is available through any FBM or Last Call dealer or can be ordered direct from FBM at the Last Call online store.  Quantities are limited so if you aren’t able to get one from this batch, contact us to reserve one from the next one.

fbm sword 56sq frameset flat black profileview Read The Rest

The Orphan, Kenny Horton

The Orphan, designed and ridden by Kenny Horton, handbuilt in New York by FBM, is coming soon.

Check out Kenny riding his prototype frame is this video filmed by Steve Crandall, Latane Coghill and Charlie Crumlish.

Click the link below to subscribe to the FBM YouTube channel

Alexis Mabry – Rider Profile

Alexis Mabry with Sword
Alexis Mabry is an artist living in Richmond Va, via Philly and the Dallas area, who has contributed to several FBM projects, including T-shirt graphics, the Shark ramp From the Gwar- BQ, and has her own brand – Neva Safe!

https://www.facebook.com/pages/Neva-Safe/190144011082164

Her FBM Sword build up is a modest commuter build, that’s been stolen once, recovered, and ridden countless miles, as it’s her primary source of transportation. The unicorn Sword Mask (scroll down) is part of an upcoming Neva Safe art show celebrating Awesomeness!

Read The Rest

FBM Summer Tour Starts Today

fbm qbmx summer tour

And they’re off…

The FBM Crew hits the road today for the FBM x QBMX Bustin Loose Summer Tour.

Hang out and ride with the crew throughout the North East with scheduled stops at:

Follow the FBM Crew on Instagram
